Bottom spouted fluidized bed coating machine is Spray technology and fluidized coating technologies as one of the particles of powder coating equipment, bottom spray fluidized material having a regular "donut" running track, bottom spray fluidized, continuous film coating.
Typical applications: pills, granules, powder coatings, modified release film-coated skeleton slow release capsules.
Lysine granulation coating, omeprazole sustained release coating, in line with sustained-release coating fat, coating Herd Toukuwan, wolfberry moisture-proof coating, etc.
Features:
1, powder granules, pellets coloring, taste-masking, moisture, oxidation, water, heat, isolation coating, etc.
2, the material dispersion is very good, no adhesion problems
3, Spray short circuit, solve the "Spray drying" and other issues, without loss of coating materials, low production costs
4, inverted cone container deceleration and acceleration central tube design, can be particles, pellets, big grain, Pellets
Technical Parameters:
| project | 3 | 5 | 15 | 30 | 60 | 120 | 200 | |
| Feeding amount | Kg/Batch | 1.5-4.5 | 4-6 | 10-20 | 25-40 | 40-80 | 80-150 | 150-250 |
| Container capacity | L | 10 | 16 | 50 | 100 | 210 | 410 | 660 |
| Fan power | Kw | 3 | 4 | 5.5 | 7.5 | 15 | 18.5 | 22 |
| Amount of compressed air | M3/min | 0.25 | 0.35 | 0.6 | 0.85 | 1.1 | 1.6 | 2.2 |
| The amount of steam | Kg/h | 8kw | 50 | 65 | 90 | 180 | 280 | 35 |
| Reference dimensions | H1(mm) | 1950 | 2360 | 2850 | 3120 | 322 | 3450 | 3660 |
| H2(mm) | 310 | 310 | 340 | 340 | 490 | 590 | 690 | |
| H3(mm) | 1750 | 2030 | 2530 | 2800 | 2900 | 3130 | 3350 | |
| ø1(mm) | 400 | 550 | 700 | 1000 | 1200 | 1600 | 1800 | |
| Ø2(mm) | 150 | 150 | 250 | 250 | 280 | 280 | 315 | |
| B1(mm) | 660 | 1050 | 1160 | 1460 | 1660 | 2060 | 2260 | |
| B2(mm) | 1200 | 1650 | 1860 | 2460 | 2860 | 3660 | 4060 | |
| B3(mm) | 880 | 950 | 1400 | 1500 | 1600 | 1800 | 2000 | |
