Application
※Pharmaceutical industry: tablets, granules, capsules, granules; sugar, sugar-free medicine particles.
※Food: cocoa, coffee, milk powder, granule juice, spices;
※Other industries: pesticides, feed, fertilizer, pigments, dyes and the like;
Feature
※Set spray drying, fluidized granulating in one step granulation liquid materials to achieve;
※Spray process, especially for micro materials, heat-sensitive materials, effect than FL boiling granulating machine 1-2 times.
※Product final moisture of up to 0.1%, with the anti-powder device, granulating rate of & ge; 95%, can be prepared 0.2-2mm particles.
※Improved design within the mixed multi-fluid atomizer, the proportion of extract can handle up to 1.3g / cm3.
Technical Specifications
| project | Aircraft Unit | PGL-3B | PGL-5B | PGL-10B | PGL-20B | PGL-30B | PGL-80B | PGL-120B | ||
| Liquid extract | Least | kg/h | 2 | 4 | 5 | 10 | 20 | 40 | 55 | |
| maximum | kg/h | 4 | 6 | 15 | 30 | 40 | 100 | 140 | ||
| Boiling capacity | Least | kg | 2 | 6 | 10 | 30 | 60 | 100 | 150 | |
| maximum | kg | 6 | 15 | 30 | 80 | 160 | 250 | 450 | ||
| Hydrometer | kg/L | ≤1.30 | ||||||||
| The amount of raw container | L | 26 | 50 | 100 | 220 | 300 | 670 | 1000 | ||
| Vessel Diameter | mm | 400 | 550 | 770 | 1000 | 1200 | 1400 | 1600 | ||
| Induced draft fan power | kw | 4.0 | 5.5 | 7.5 | 15 | 18.5 | 22 | 30 | ||
| Auxiliary fan power | kw | 0.35 | 0.75 | 0.75 | 1.10 | 2.20 | 2.20 | 3 | ||
| steam | Consumption | kg/h | 25 | 50 | 120 | 160 | 240 | 280 | 300 | |
| Mpa | 0.40-0/60 | |||||||||
| Electric type power | kw | 9 | 15 | 21 | 25.5 | 51.5 | 60 | 75 | ||
| Compressed air | Consumption | m3/min | 0.4 | 0.6 | 0.9 | 0.9 | 1.1 | 1.3 | 1.6 | |
| pressure | Mpa | 0.20-0.60 | ||||||||
| Operating temperature | ℃ | Automatically adjust room temperature -130 ℃ | ||||||||
| Product moisture | % | ≤0.5%(Depending on the specific materials may be) | ||||||||
| Material yield | % | ≥99% | ||||||||
| Equipment noise | dB | ≤70 | ||||||||
| Host size | Φ | mm | 400 | 550 | 770 | 1000 | 1200 | 1400 | 1600 | |
| H1 | mm | 940 | 1050 | 1070 | 1180 | 1620 | 1620 | 1690 | ||
| H2 | mm | 2100 | 2400 | 2680 | 3150 | 3630 | 4120 | 5050 | ||
| H3 | mm | 2450 | 2750 | 3020 | 3700 | 4100 | 4770 | 5800 | ||
| B | mm | 740 | 890 | 1110 | 1420 | 1600 | 1820 | 2100 | ||
